KSJ-0.7S SERIES Portable Fume Extractor For Metal Welding Soldering Fume Extractor Mobile Machine

Working principle

Cleaning: when dusts accumulate continuously on filter cartridge's layer surface, the pressure difference between it's interior and exterior will increase steadily, when the pressure difference reach pre-set value(1000-1500Pa), the pulse valve will open, dry, oil-free compressed air rush into the reverse blow cleaning system. The system rotate and high pressure air stream jet at the interior of filter cartridge, blow off dusts accumulated on the filter cartridge's layer surface, dusts fall into dust collector under gravity, thus the whole cartridge's layer surface is cleaned.

Product introduction
Incorporated world leading environmental technology, double working bay double filter cartridge fume purifier is a technically advanced industrial dust & fume purifier, it's developed with full consideration of the forming, characteristics and harm of fume and based on actual conditions of cutting and welding workshop.

This purifier can be automatically cleaned and manually cleaned, automatically cleaning is as following:
1. When air pressure difference reach 1500Pa between the interior and exterior of the filter cartridge, the system will implement interval rotation pulse blow cleaning.
2. When the fan stops working, the system will implement interval rotation pulse blow cleaning for three times.

Ksj-0.7s Series Portable Fume Extractor for Metal Welding Soldering Fume Extractor Mobile Machine

Main feature
1. Suction arm can be rotated 360° horizontally, according to actual working condition, suction volume can be adjusted by adjusting volume valve in suction hood.
2. PTFE coating(highly effective glass fiber)micro particle filtration, filtration efficiency reaches 99.99%, meanwhile maintain a high air flow

3. purifying dry, oil-free, non-corrosive fume mixture generated in cutting and welding, collecting rare metals and valuable materials

Ksj-0.7s Series Portable Fume Extractor for Metal Welding Soldering Fume Extractor Mobile Machine


Technical parameters
Noitemparameter
1fan typeKSJ-0.7S
2treatment of air flow1000m3/h
3motor power0.75kw
4power supply220V/50Hz
5filtration area15m²
6number of filter cartridges1pieces
7filter mediumNanometer Fiber
8filtration efficiency>99.9%
10compressed air0.5~0.6 MPa
11maximum pressue1900Pa
12noise74±5dB(A)
13weight98±5KGS
14dimensions(excluding suction arm)510×610×990mm
