Niwo Stainless Steel Water Pipe Flat Quick Coupling ISO 16028 Coupling

 NWP4 series quick coupling (stianless steel) Product FeatureMeet the standard ISO16028  Push and pull connectionWith safe lock to avoid accidental disconnectionCorrosion resistance for bad environment  Standard material:stainless steel 304/316Standard seal:fluoride rubber( FKM) Seal elastomer

Featured Products


NWP4 series quick coupling (stianless steel)


Product Feature
  1. Meet the standard ISO16028
  2. Push and pull connection
  3. With safe lock to avoid accidental disconnection
  4. Corrosion resistance for bad environment
  5. Standard material:stainless steel 304/316
  6. Standard seal:fluoride rubber( FKM)

Seal elastomer data
Seal    Maximum working temperature range
Fluoride rubber  -25ºC to +150ºC

Size
(in)
ISO
(mm)
Max Working Pressure
(bar) / (psi)
Rated Flow
(l/m)
connection
1/46.3250 / 360012
3/810250 / 360023
1/212.5250 / 360045
3/420250 / 360074
125250 / 3600100




Application Range

Building
Agriculture
Steel manufacture
Railway
Oil and natural gas
Ocean
Material processing
Universal hydraulic purpose



Interchangeability

Faster--2FFN/2FFI series
Parker--FEM series
Hansen--FF series
Aeroquip--FD89 series




Photo Details


Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling
Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling






Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling




Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling




Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling






Naiwo Stainless Steel Water Hose Flat Face Quick Coupler ISO 16028 Coupling










Link of ISO16028 Flat Face Coupler Zn Plated & Zn-Ni Plated(steel):

http://naiwocoupling.en.made-in-china.com/product/LKvJtcfjvRpa/China-ISO-16028-Flat-Face-Coupler-Zn-Plated-Zn-Ni-Plated-Hydraulic-Quick-Coupling-Socket-Nut-steel-.html
