Ventilation exhaust fan ventilator poultry ventilation fan
1. 50'' Galvanized box fan ,with frames of 1.0mm.
2. Galvanized material 275g.
3. Shutter thickness at 1.2mm in the middle and the others are 0.8mm,
4. 430# stainless steel 6 blades
5.Belt imported from the United States. Double-sealed single-plate thickened bearings
|No.||Model||Air volume m³/h (Pressure 0 Pa)||Energy efficiency ratio m³/h/w||Rated power W||Rated voltage||Rated current A||Drive mode||Blade speed||Blade material||Size W*H*T||Hole size mm||Gross weight kg|
|1||GFFD-1380-TP||44000||31||1100||380V||2.8||Belt||456||430 stainless steel||1380*1380*450||1400*1400||77|
|2||GFFD-1000-TP||23000||23||750||380V||1.99||Belt||648||430 stainless steel||1000*1000*450||1020*1020||48|
|3||GFFD-800-TP||10700||23||370||380V||1.07||Belt||605||430 stainless steel||800*800*450||830*830||33|
Heze Gofee Motor Co., Ltd was established in 2008. We are specialized in producing climate control equipment and deliver cost competitive product for livestock farm customers. Now we are supplier for famous companies such as Zhengbang Group, Elephant Group, Xinnong Share, Wenshi Group, etc, and become newly pioneering company in this industry in China.
In October, 2016, new factory with 20000 sq.m. was put into use. Our new factory is equipped with fan shell mould shaping machine, auto fan assembly line, auto motor production line, large pressure equipment, wind tunnel test lab, motor test system, terminal test system, cooling pad production system, and etc. The equipment are highly automated with high precision. Production and test process are strictly controlled to guarantee gofee products in high quality. We own a technical research center and have a team of talented technical designers and engineers focusing on bettering climate control solution.
We have been certified by ISO9001, CCC, CE, SGS and the fan of 18"/24"/36"/51"passed BESS LAB( Bioenvironmental and Strutural Systems Lab in the University of Illinois) Certification.
Our product range from glassfibre variable speed/fixed speed cone fan, roof fan, cooling pad, air inlet, electrical controller, climate controlling equipment, voltage or speed adjusting motor for fan, disassembly/wholly assembled speed reducer, standard high efficient motor, glassfiber FRP tower, glassfiber product, etc.
Equipment and Test Facilities
The new factory is equipped with fan shell mould shaping machine, auto fan assembly line, auto motor production line, large pressure equipment, wind tunnel test lab with A3000 Inlet Chamber Tester, motor test system, terminal test system, cooling pad production system, etc. The equipment are highly automated with high precision. Production and test process are strictly controlled to guarantee gofee product in high quality and consistence. We own a technical research center and have a team of talented technical designers and engineers, focus on better climate control solution.
Certificate and Honor
Concept of Our Business
We supply this high quality products with favorable price. We're pleased to get your Inquiry and we will reply you as soon as possible. We stick to the principle of " Quality first, service first, and continuously improve our production by innovation and meet the customers needs. We are obedience to " Zero defect, zero complaints" as the quality objective. We try our best to make our production performs good and to meet your needs.
